JACK JK-58750B-005C BASIC 6.4MM TWIN NEEDLE KNOCK OUT
Why Buy from Us?
- You are dealing with the official Jack UK Importing and Distributing Network
- Your machine enquiry will be passed onto your local Jack dealer who will quote, setup, and install your new machines. As well as providing full after sales support and warranty
- Our centralised distribution warehouse supplies Jack machinery to all Jack Traders, providing the best possible service and local contact for your sewing requirements
Description / JACK JK-58750B-005C BASIC 6.4MM TWIN NEEDLE KNOCK OUT
Jack JK-58750B-005C
- Basic Twin Needle Heavy-Weight Lockstitch Machine – Large Hook / Knock-Out Needles.
Basic direct drive lockstitch machine with dual needles. Designed with a spacious work area, voice guidance system, and oil level indicator for enhanced usability and efficiency.
Machine Type
58750 large hook disengageable needles
Electronic Tension
The tension discs are electronically controlled, replacing traditional mechanical steel cable systems. This allows precise adjustment of timing and responsiveness for improved stitch quality and consistency.
Voice Guide
The machine will guide you through its various functions automatically. If any errors occur, it will notify you. By pressing the VOICE button, you will receive suggested solutions to the problem. Additionally, a single RESET button allows you to restore the system to its original settings.
Integrated Footlifter
In addition to the thread trimmer, bartack, and thread wiper devices, the automatic presser foot lifter is fully integrated into the machine's body. This design ensures enhanced safety, quieter operation, and a sleek, attractive appearance.
Single Shaft Motor
The internal single-axis shaft motor design reduces torque, effectively minimizing vibrations. This results in a smoother, faster, and quieter operation with enhanced stroke stability.
Spacious Work Area
With dimensions of 264 mm × 120 mm, the expanded workspace makes it easier to rotate garments and handle a wide range of fabric types comfortably and efficiently.
Self-Cooling Handwheel
The internal design of the handwheel promotes efficient air circulation, helping to reduce motor temperature and extend the lifespan of electronic components.
LED Lighting
Three adjustable levels of LED illumination provide consistent, glare-free light, reducing eye strain during sewing and threading operations.
Direct Drive Motor
The 750W eco-friendly motor ensures powerful needle penetration while delivering up to 71% energy savings compared to conventional motors.
Industry 4.0 (Optional)
With the integrated Wi-Fi module, you can adjust machine parameters and monitor productivity directly through the app.
Note: A Jack Gateway is required for every 50 machines.
Technical Specification
| Model | Jack JK-58750B-005C |
|---|---|
| Application | Heavy-Weight |
| Function | Corner Stitch |
| Needle | DPx5 11-16# / 14-22# |
| Stitch Length (mm) | 7 |
| Needle Guage (mm) | 6.4 |
| Presser Foot Lifting Height | 7-13 |
| Max Sewing Speed (S.P.M) | 3000 |
| Large Hook | Yes |
| Volume (mm) | 725x320x675 |
| Weight (KG) | 43/53.5 |
More Information
| Part No | JACKJK58750B005C |
|---|---|
| Weight (KG) | 0.100000 |
| Manufacturer | Jack |
